TSC-TTP-247-THERMAL-PRINTER

TSC® TTP-345

  • Easy access “clam-shell” design.
  • Low to medium volume printer.
  • Label widths up to 104mm.
  • Label gap sensor and “black mark” sensor.
  • 300dpi print resolution.
  • 100 to 200 labels per minute. (*variable)
  • USB; parallel; serial interfaces.
  • 4 MB flash and 8 MB SDRAM memory.
  • Optional external label roll holder.
  • Optional keyboard.

TSC® TTP-345 THERMAL PRINTER

The TSC® TTP-345 is a desktop thermal label printer suitable for low to medium volume printing of garment identification and barcode labels. The small frame and “clam-shell” design allows for minimal space, easy supply access and lightweight portability. The printer is capable of handling labels up to 104mm wide and prints at a controlled resolution of 300dpi. The TTP-345 can process labels at speeds that range between two and five inches per second, making it possible to print at least 100 to 200 continuous garment identification labels per minute, relative to data flow, print resolution, label format and size. The printer comes with standard USB, parallel and serial interfaces. Ethernet and wireless modules are optional.

For accurate label to label alignment, the TTP-345 is equipped with sensors to detect perforated label notches or the gaps between pressure sensitive labels that are supplied on a silicone label carrier in continuous form. The printer is also able to detect registration marks that may be printed on the reverse side of some label tapes. The TTP-345 can be paired with an optional external label tape roll holder, and can be interfaced with an optional data entry keyboard. If 203dpi printing is required, please review the TTP-247 model.
